Quality service ISO,CE Quality Approved Reversible Impact Hammer Crusher PCFK-1214 manufacturer from China Shenzhen Yuhan electro-mechanics Co., Ltd

Quality service ISO,CE Quality Approved Reversible Impact Hammer Crusher

Payment Terms:	T/T,L/C;O/A
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: PCFK-1214

Production Capacity: 200 sets/month

Delivery Date: 20 days

Type: Crusher

Model: PCFK-1214

Rotor length: 1400 (mm)

Capacity: 120-220 (t/h)

Power: 220-280 (KW)

Means of Transport: Ocean,Land,Air,

Packing: normal packing

Application: Coal

Brand Name: RP

Rotor diameter: 1200 (mm)

Feeding size: ≤80 (mm)

Rotary speed: 740 (r/min)

Weight: 21 (t)

Reversible Impact Hammer Crusher
1)ISO,CE impact hammer crusher
2)Easy maintenance crusher
3)Stable performance crusher

Quality service PCFK Series Reversible Impact Hammer Crusher

1. Brief introduction of Reversible Impact Hammer Crusher

PCFK Series of Reversible Impact Hammer Crusher has advantages of both Hammer Crusher and Impact Crusher. It can break brittle materials of medium hardness, such as coking coal, anthracite, coal used for fluidized bed boiler of heat power plant, coal gangue, gypsum, alum, etc.

2. Working Principle of Reversible Impact Hammer Crusher

Materials enter crushing chamber from feeding hopper, and are impacted to wear-resisting toothed plates on inlet by high speed hammers, this is the first crushing process. Crushed materials with almost the same size enter the main crushing chamber for second crushing. Materials from main crushing chamber are impacted between toothed plates and hammers for many times, and discharged from the outlet. Final product size can be controlled by adjusting space between rotor and impact plates.

3. Types of Reversible Impact Hammer Crusher:

We have various of Reversible Impact Hammer Crusher,such as PCFK-1212, PCFK-1214, PCFK-1216, PCFK-1414, PCFK-1416, PCFK-1616, PCFK-1618, PCFK-1818etc. In order to give you a responsible quotation, you can inform us the following information:

1). What's the material you are going to deal with?

2) What's the granularity of the material?

3) What's the granularity of the final products are you going to achieve?

4) What's the producing capacity you are going to achieve?

Our engineers will suggest you the most suitable one for you according to your information.

4. Technical parameters of Reversible Impact Hammer Crusher

Model	Rotor diameter (mm)	Rotor length (mm)	Feeding size (mm)	Discharge size (mm)		Capacity (t/h)	Rotary speed (r/min)	Power (KW)	Weight (t)
Model	Rotor diameter (mm)	Rotor length (mm)	Feeding size (mm)	100%	93%	Capacity (t/h)	Rotary speed (r/min)	Power (KW)	Weight (t)
PCFK-1212	1200	1200	≤80	0-8	0-3	100-180	740	220-280	19
PCFK-1214	1200	1400	≤80	0-8	0-3	120-220	740	220-280	21
PCFK-1216	1200	1600	≤80	0-8	0-3	150-250	740	315-355	24
PCFK-1414	1400	1400	≤80	0-8	0-3	220-300	740	355-450	25
PCFK-1416	1400	1600	≤80	0-8	0-3	250-330	740	355-560	30
PCFK-1616	1600	1600	≤80	0-8	0-3	280-350	740	450-560	32
PCFK-1618	1600	1800	≤80	0-8	0-3	300-400	740	560-710	37
PCFK-1818	1800	1800	≤80	0-8	0-3	400-450	740	710-800	45
PCFK-1820	1800	2000	≤80	0-8	0-3	450-500	740	800-900	50
PCFK-1825	1800	2500	≤80	0-8	0-3	500-550	740	900-1000	60
