Hydraulic Crusher Cone Crusher [Multi-Cylinder Hydro-Cone Crusher] HPC-160 manufacturer from China Shenzhen Yuhan electro-mechanics Co., Ltd

Hydraulic Crusher Cone Crusher [Multi-Cylinder Hydro-Cone Crusher]

Price:	1000.0~10000.0 USD
Payment Terms:	T/T,L/C
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: HPC-160

Production Capacity: 200 sets/month

Delivery Date: 20 days

Type: Crusher

Cavity: C (coarse/fine)

Feed size: 150 (mm)

Power: 160 (kW)

movable cone diameter: 950 (mm)

Means of Transport: Ocean,Land,Air

Packing: normal packing

Application: Coal

Brand Name: RP

Min. discharge size: 13 (mm)

Capacity: 120-240 (t/h)

Weight: 13 (t)

Professional Cone Crusher Manufacturer;
Recognized Stable Performance;
9001:2008;
40-90 days

HP Series of highly efficient Hydraulic Cone Crusher is a world-level cone crusher introduced with the up-to-the-minute technology of Germany. The cone crusher not only improves the production capacity and crushing efficiency, but also widens applying area, hardness range of materials from limestone to basalt. It has a great crushing performance in the work of medium-size crushing, fine crushing and super fine crushing. The crusher is the improved type of spring cone crusher and can be used to replace ordinary hydraulic cone crusher in the field of mining and construction. It is the most ideal equipment for large stone crushing factory and mining industry.

Technical Data:

Type	Cavity (coarse/fine)	Min. discharge size (mm)	Feed size (mm)	Capacity (t/h)	Power (kW)	Weight (t)	movable cone diameter (mm)
HPC-160	C	13	150	120-240	160	13	950
	F	6	76	55-180
HPC-220	C	13	225	150-430	220	18	1160
	F	6	86	90-260
HPC-315	C	13	290	190-610	315	26	1400
	F	6	100	108-320
HPC-400	C	13	320	230-700	400	33	1500
