high quality vertical shaft impact crusher,sand making crusher Y3S1848V81 manufacturer from China Shenzhen Yuhan electro-mechanics Co., Ltd

Product Detail

Model No.: Y3S1848V81

Production Capacity: 200 sets/month

Delivery Date: 20 days

Type: Crusher

Transportation size: 13500×2830×4350 (mm)

Tire Configuration: Dualaxial

The Maximum Feeding Size: 31 (mm)

Belt Conveyor Under Vibrating Screen: B800×7M

Means of Transport: Ocean,Land

Packing: normal packing

Application: Coal

Brand Name: RP

Weight: 36 (t)

Vertical Shaft Impact Crusher: VSI-8518

Capacity: 100-260 (T/h)

vertical shaft crusher
1.ores and rocks with various hardness
2.lower running cost
3.crusher for stone ,coal and so on

Features:

1. High capacity
2. fine crushing and shape adjusting
3. high performance, flexible
4. integral crushing & screeing
5. belt conveyor self-loaded

Mobile Vertical Shaft Impact Crusher

Technical Data\Model			Y3S1848V81		Y3S1860V92		Y3S2160V140
Transportation size (mm)			13500×2830×4350		15600×2830×4350		15600×3100×4480
Weight(t)			36		48		61
Tire Configuration			Dualaxial		Dualaxial		Triaxial
Vertical Shaft Impact Crusher			VSI-8518		VSI-9526		VSI-1140
The Maximum Feeding Size(mm)			31		36		49
Capacity(T/h)			100-260		150-380		225-520
Belt Conveyor Under Vibrating Screen			B800×7M		B800×8M		B1000×8M
Self-loaded Belt Conveyor			B800×2.2M		B800×2.5M		B1000×2.5M
Vibrating Screen			3YZS1848		3YZS1860		3YZS2160
Electric control	standard	control box + control panel		control box + control panel		control box + control panel
	Optional	Control box + LCD		Control box + LCD		Control box + LCD
Hydraulic leg	standard	4		4		4
	Optional	2		2		2
Hydraulic cyclinder	standard	0		0		0
	optional	2		2		2
Genset (optional) (Kw)			330		440		600
