jaw fine crusher & hot sell rock crusher jaw crusher used in mining PE900*1200 manufacturer from China Shenzhen Yuhan electro-mechanics Co., Ltd

jaw fine crusher & hot sell rock crusher jaw crusher used in mining

Payment Terms:	T/T,L/C;O/A
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: PE900*1200

Production Capacity: 200sets/per month

Delivery Date: 20days

Type: Crusher

Model: 800*800

Max. Feeding Size (mm): 750

Overall Dimensions (mm): 3789*2826*3025

Means of Transport: Ocean,Land,

Packing: normal packing

Application: Ore

Brand Name: RP

Size of Feeder Opening (mm): 900*1200

Motor Power (kW): 110

Weight (t): 54.5

PE900*1200 PE series Jaw Crusher
1.High ratio of crushing,
2.homogeneous final grain size,
3.simple structure,

ore jaw crusher/ jaw fine crusher used in mining for sale

PE 900*1200 Jaw Stone Crusher

Jaw Crusher is mainly used to crush kinds of mining stones primarily, and the largest compression resistance of the material is 320MPa. The jaw crusher is widely used in stone mining, metallurgy industry, building material, highway, railway, and chemical industry.

Working Principle of Jaw Crusher:

The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves . So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet.

Our Jaw Crusher series are based on years' experience and technology development. The continuous improvement and refinement has made them the preferred jaw crusher for professionals and our customers. They can meet most crushing requirements in primary and secondary crushing, and the largest compression resistance of the material is 320MPa. This series are widely used in stone mining, metallurgical, construction, smelting, hydraulic and chemical industries, etc.

Jaw Crusher PE900×1200

Characteristics of Jaw Crusher PE900×1200:

-High ratio of crushing,
-homogeneous final grain size,
-simple structure,
-reliable working condition,
-easy maintenance,
-low operating cost..

Technical Data of Jaw Crusher PE900×1200:

Model	PE900×1200
Size of Feeder Opening (mm)	900×1200
Max. Feeding Size (mm)	750
Capacity (t/h)	160-380
Motor Power (kW)	110
Overall Dimensions (mm)	3789×2826×3025
Weight (t)	54.5
