mineral beneficiation flotation plant for processing gold, copper

Payment Terms:	T/T,L/C
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Means of Transport: Ocean,Land

Packing: normal packing

Application: Coal

Production Capacity: 200 sets/month

Delivery Date: 20 days

Type: Others

1.mineral beneficiation flotation plant
2.Capacity 0.18-7 (m3/min)
3.high ore recovery rate 80-90%
4.ISO9001: 2000

1.Products application: metal ore such as gold, silver, copper, Lead (Pb), Zinc (Zn), Tin, Nickel (Ni) and so on.

Flotation plant main equipment: crusher, ball mill, classifier, mixing tank, flotation machine.

2.Working Principle: The Flotation Machine was driven by the motor with the working of impeller rotation, and then produces the centrifugal effect, and form the negative pressure. On one hand, absorbing enough air to mix with the pulp; on the other hand, stirring the mixture of pulp and drugs, in the meanwhile, refining bubble, make the mineral adsorbed on bubbles, float to the pulp surface and form the mineralized bubble . Adjust the flashboard height, control the pulp surface, make the foam scraped by the scraping plate.

3.Flotation Machine Features:

A.large inspiratory volume, and low power consumption;

B.each trough has inhale, midge and flotation from a flotation circuit, without any auxiliary equipment, configuration installation, easy to change the process.

C.Slurry tank for the next cycle, which is conductive to the suspension of coarse mineral recycling;

D.Slutty hand control, automation and electric control devices, easy to adjust;

EThe impeller is made up of dual cut cone, they can produce a strong pulp cycle;

F.The SF Series flotation machine is widely used for the separation of the non-ferrous metals, ferrous metals, precious metals, nonmetallic minerals and the chemical, for the recycling of useful materials.

4.Flotation Machine Technical Parameters:

Model		SF0.37	SF0.7	SF1.2	SF2.8	SF4
Tank Volume (m³)		0.37	0.7	1.2	2.8	4
Impeller Dia (mm)		300	350	450	550	650
Capacity (m³/min)		0.2-0.4	0.3-0.9	0.6-1.2	1.5-3.5	0.5-4
Impeller Rotate Speed (m³/min)		352	400	312	268	238
Motor	Model	Y90L-4	Y100L2-4	Y132M2-6	Y160L-6	Y180L-6
	Model	Y90S-4	Y90S-4	Y90S-4	Y90S-4	Y90L-4
	Power (Kw)	1.5	3	5.5	11	15
	Power (Kw)	1.1	1.1	1.1	1.1	1.5
Overall Dimension (mm)		700×700×750	900×820×950	1100×1100×1100	1700×1600×1150	1850×2050×1200
Unit Weight (kg)		468	600	1373	2338	2660

Main Technical Parameters of XJK Series Flotation Machinery

Model			XJK-0.35(3A)	XJK-0.62(4A)	XJK-1.1(5A)	XJK-2.8(6A)	XJK-5.8(7A)
Effective Volume(m3)			0.35	0.62	1.1	2.8	5.8
Capacity(m3/min)			0.18~0.4	0.3~0.9	0.6~1.6	1.5~3.5	3~7
Rotate Speed(r/min)			470	400	330	280	240
Impeller Dia (mm)			300	350	500	600	750
Motor	Model	Rotator	Y90L-4	Y100L2-4	Y132M2-6	Y160L-6	Y200L2-6(Y225M-6)
	Model	Scraper	Y90S-4	Y90S-4	Y90S-4	Y90S-4	Y90L-4
	Power(Kw)	Impeller Motor	1.5	3	5.5	11	22(30)
	Power(Kw)	Scraper Motor	1.1	1.1	1.1	1.1	1.5
Weight(t/Single Tank)			0.43	0.86	1.38	2.33	3.533
